功能与百科/Purpose and introduction：

NQGF型西林瓶粉针洗烘分开装袋轧盖标贴签签协同线 由QCL产品品类柜式彩超波洗瓶机、AQMR隧道施工式热气间歇消毒干燥箱、NQFGX产品品类数控机床螺旋轴粉剂分开装袋机、NQ-50轧盖机、NQWTB-120标贴签签空气能成，也可单机手机游戏动用。适用于7-25ml规模的西林瓶粉针的产量。能做好喷淋除垢充水、彩超波粗洗、瓶侧壁水喷洗、瓶壁上重复多次间歇水喷洗、每次吹气、每次生鲜水喷洗、重复多次吹气、瓶侧壁吹气、除垢、发动机预热、干燥消毒去热原、冷却后、分开装袋、加塞、轧盖、标贴签签等二十几道工艺程序。NLGF schering bottles booster injection wash baked repackaging rolling cover labeling line consists of QCL series vertical ultrasonic bottle washer, ASMR tunnel type hot air circulation oven. NFFGX series CNC screw powder filling machine, NF-50 rolling machine, NFWTB-120 labeling machine, and also can be used stand-alone. Suitable for 7 to 25 ml specification schering bottles of water production. Can finish the spray water injection, ultrasonic thick bottle washing, the outer wall of water flushing, bottle wall continuous secondary circulating water flushing, a blowing, a fresh water rinse, two consecutive bottle blowing, blowing the outer wall, preheating and drying sterilization to pyrogen, cooling, packaging, gasser, cover, labeling and so on more than 20 procedures.

优缺点/characteristic：

◆洗瓶机用到机械厂手夹瓶，常用多重年纪的西林瓶；Bottle washer adopts manipulator clamp bottle, is suitable for a variety of specifications of schering bottles;◆洗瓶利用雾气喷针反复关注导入具体方法，擦拭成果好，节约用电自然能源。并设置针架防颤抖试验装置，不断提高喷针导入塑料瓶的明确度，减轻断针不良现象进行；Reciprocating mixer washing bottle with water spray needle track insert way, cleaning effect is good, save energy. And is equipped with needle shake device, improve the accuracy of injection needle inserted into the bottle, reduce breakage phenomenon;◆洗瓶另一气水导压管、喷针已经独力在一起，不要了相互水污染，达到GMP规范性需求；Mixer washing bottle the water pipe, injection needles completely separate, to avoid the cross contamination, in line with the GMP requirements;◆洗瓶机进瓶丝杆前选配降低块，有庇护丝杆，以减少碎瓶能力；Pieces into the bottle inside the screw before adding buffer block, protect the screw, reduce broken bottle;◆洗瓶机出瓶选取局部美国进口发送到带，接连拨瓶块输送管西林瓶，正常运行保持稳定可以信赖；Pieces out of the bottle inside the whole import synchronous belt, the connection dial the bottle conveying schering bottles, operation is stable and reliable;◆真空烘箱进行内间歇间歇高温，热度不均，工业节能；Oven adopts hot air circulation heating, temperature uniformity, energy saving;◆烘烤箱设置有防总是关电保護性能。启动的安全；Mixer oven has suddenly loses power protection function. Run security;◆恒温干燥箱可配循坏水冷式传动装置，不损耗费小房新风量，可以减少小房的压值不稳定平衡的高风险提温治疗最合适；Mixer oven can match circulating water cooling device, not loss room air volume, reduce the risk of differential pressure imbalance in room cooling effect is good.◆烘干箱可配压力差大智能均衡调控整体限制房和烘干箱的压力差大不均衡引发的高温高压段偏斜，装灌间洗烘间平均温度升等一系类的问题；Mixer automatic oven can match differential pressure balance control system to reduce the room and high temperature oven pressure difference caused by the imbalance of period of migration, filling between wash between baking temperature and so on a series of problems;◆烘烤箱可设DOP查重模块(是指风压差、风压、尘灰塑料颗粒查重口)；Mixer oven with DOP test interface (including wind pressure, wind speed, dust particle detection);◆真空烘箱加热段可带在线播放无菌功效(FDA特选)；Mixer oven cooling segment with the function of sterilization (FDA selected);◆烤箱网带可带超声清洁工作牵连CIP网络清洁工作机系统；Type mixer oven mesh belt with ultrasound scanning CIP online cleaning system;◆恒温干燥箱内腔室可对其进行全位子、多的角度高压低压水喷洗；In pieces inside the oven chamber can be all-round, multi-angle high-pressure water flushing;◆预包装机选取国家更高级的设计的观念，有着快速路度，同时分瓶准确的，换成规格为件以便于；Mixer racking machine adopts the most advanced design concept, high speed, and bottles of accurate, replacement of a convenient;◆包装机所采用洽谈伺服线束发电机win7驱动包装螺旋轴360度旋转，装量透彻；Mixer racking machine adopts ac servo motor drive the repackaging screw rotation, the load accurately;◆全自动灌装机机主要包括装量的整改一直在摸屏上完成；Mixer packer adopts the load adjustment directly on a touch screen;◆包装机必选配百级配置式层流罩；Mixer packer optional circulating laminar flow hood best level;◆全自动灌装机机无瓶停止工作全自动灌装机，无瓶要加塞工作。Racking machine without stop packing bottle, no bottle no stoppered function.◆整线采取PLC总保持、交流abb变频器、触屏屏保持能力，手动执行稳定的安全稳定可靠。触屏屏可表示各手机单机的手动执行阶段，各保持点的水管打压、压力、风速、温等表示，各打开阶段和内部内部告警表示，内部内部告警自我管理诊治和内部内部告警阐述及查出方式方法。使整个的出产环节达到了手动化保持，联线含有自动化动平衡安装，以确保出产多样化安全稳定可靠。The whole line adopts PLC control, inverter, touch screen control technology, stable and reliable running. Touch screen can display the running state of each units, each control point of the water pressure, air pressure, air pressure, temperature, etc, according to the switch state and fault display, fault self-diagnosis and fault analysis and elimination method. Make the whole production process automation control, on-line has the automatic balancing device, ensure production equilibrium is reliable.随着业主的要，还可供标准配置：According to the needs of customers, but also available for selection:◆西门子机系统、斯耐德、三菱数控机系统、台达等的品牌的控制机系统；Pieces of Siemens, schneider, mitsubishi, Taiwan brands such as control system;◆水、气压力差、油温及mri波密度、颗粒粒子束、风量线下验测、报警装置、记录好、直接打印整体；Pieces of water, gas pressure, water temperature and the intensity of ultrasonic, dust particles, wind speed on-line detection, alarm, record and print system;◆ORABS、CRABS、没有细菌消毒器控制系统。ORABS, CRABS, aseptic isolator system.

技术性运作：/technical parameters

款型 model

产量水平production capacity

洗瓶通过率率Washing bottle percent of pass

洗瓶脏污率Washing bottle breakage

杀菌体温sterilizing temperature

分开装袋误差率The repackaging of error

加塞及格率Gasser percent of pass

室内空气层流净化度Laminar air cleanliness

真空体抽速Vacuum pumping speed

电解电容量 capacitance

24v电源power supply

总充电Total transmission energy

外观设计尺寸boundary dimension

7-25ML国家标准西林瓶 7-25ML GBvial

300瓶pcs/分min ～600瓶pcs/分min

≥99%

≤0.1%

300℃-350℃

≤±3%(0.1-10h)

≥99%

100级100c

25m3/H(外配)100cbm/H ～50m3/H(外配)100cbm/H

96kw～235.5kw

380v,50HZ

约 8200KG

约 2000×1750×2370mm
