用处与简单介绍/Brief Introduction：

机器组为10-20ml内服液液态装灌种植线种植线中的大部分产量机。是由洗瓶、吹干立体式机和装灌种植线塑封立体式机所结构，能自己成功内服液瓶的洗瓶、吹干、装灌种植线和塑封等行为，是内服液种植工厂更梦想的模块化产量机，根本适合GMP标准。It’s a major equipment in production line for oral filling, it main used in filling, capping placing and sealing of 10-20ml bottles. Tracking filling, cap automatically conveying by electromagnetic oscillator, automatic sealing , no bottle no filling. Filling and sealing integrated in one machine, advanced design, compact structure and completely comply with requirement of GMP

作用/Characteristic：

◆装量精密，预防滴漏问题。灌装设备定位精度大。High filling accuracy.◆变频器无及变频调速，制作时速能调，可供选择择与众不同的制作时速。Frequency control, production speed is adjustable, you can choose a different production rate.◆所有的家电pcb板均主要包括国外进口高知名度公司。All electrical components are imported famous brands.◆智能彰显计算功用。Automatically countting function.◆设定所采用岛国三菱数控系统PLC，抗骚扰，作业安稳。Controlled by Mitsubishi PLC◆性安全，运维护肤简单。Stable performance, easy maintenance.◆整个机器外观选用SUS304不锈304不锈钢装饰管吗作、与原材料触及部件选用316L304不锈钢装饰管吗。整个机器几乎按GMP标准设置。Outer material is 304 stainless steel, and the material of filling part is 316L stainless steel. The machine is completely designed according to GMP requirements.

技能技术指标/technical parameters：

适用于年纪/Bottle size	10-20ml
生孩子作用/Capacity	60-90瓶/min/60-90bottles/min
烘干阶段温差/Dryer tempreture	100-300°
循环水数据流量量/Water wastage	0.5m3/h
净化系统水耗量/Purifying water consumption	0.3m3/h
装量要求/Filling precision	≤1%
电压/Voltage	380V/50Hz
额定功率/Power	33KW
生孩子线总长/Dimension	3500×1500×1600mm
