功能与介绍/Brief Introduction：

滤油机是结合在一起服用液破璃瓶的新软件，彻底完美解决完美解决了之前的服用液破璃瓶的缺陷作用。四种灌封机所配的塑胶片瓶，虽然是不还要在洗瓶机、吹干机，更是不还要在消毒剂，还可以随便灌封。终端服务器全手动理瓶、进瓶、分装生产线线，分装生产线线量保持固定，无漏滴，无瓶不分装生产线线。上盖、封好率能够达到100%。此机技能先进典型，体积大概小、行驶保持固定、嗓声低，操作步骤修理、擦洗更方便等亮点，是完全具有GMP条件。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本款型有减速和高速的几种产品的生产数量供您选定 。Note: this model has two kinds of low speed and high-speed production for your choice.

结构特征 Characteristic

◆该机符合于各方面易折瓶服食液的计量灌装线和封好。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆大多数电器开关零件均采取高知名度牌子。All electrical components adopt famous brand◆该设备使用主观方面，无瓶不罐装，测量*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折pp瓶子灌封机的其主要机构与的工作原理Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型服用液易折塑料管瓶灌封机首要理瓶器、理盖器、主齿轮变速箱体系、关联带缝隙送成瓶置、空罐检漏设备、灌装生产线培训公司、去除设备、热熔胶封培训公司、自动机戒手掌夹瓶培训公司、交流伺服无刷电机无刷电机缝隙上瓶培训公司与出瓶培训公司等组合成。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆机选择的服用液易折朔胶瓶、盖是一种定超净区生产的的，需要有泡脚药材许证证，因而瓶身与底盖经传达和"去开发"后可直接的进灌封间。在理盖器、理瓶器的自动化定向生培养整里，去掉方向底盖及瓶身底口朝下的瓶，使定向生培养后的包材喂料有技巧地进输送管轨道组件中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定位后服用液易折橡胶瓶在输送管轮轨第二排Directional oral liquid after folding plastic bottles in conveying rail out easily

技巧因素technical parameters：

型号model	NLGFY-40	NLGFY-80
装量范围之内The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
封好率Hot sealing intensity	》99%
装量出现偏差的原因The load error	《1.5%
脏污率damage rate	《1.0%
工率power	2KW	3KW
电压Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
权重 Weight	700Kg	800Kg
